EcoFlow 800W Alternator Charger

The EcoFlow 800W Alternator Charger

The EcoFlow Alternator Charger features up to 800W of charging power on the move, capable of charging 1kWh in 75 minutes.

A vehicles alternator produces excess power during operation and the EcoFlow Alternator Charger uses this extra power through its onboard DC-DC boost converter to efficiently charge EcoFlow Portable Power Stations.

• Charge 1kWh in only 1.3 hours while you drive
• A 3-in-1 fast charger, maintainer, and Jump Starter/Reverse Charging
• Expands existing RV battery capacity
• Safety-assured for any journey
• Clean, easy install
• Suitable for versatile vehicles ( Vans / Campervans / Motorhome)

What’s in the box: 1. EcoFlow Alternator Charger, 2. Input Cable (5m), 3. XT150 Output Cable  (1m), 4. Fuse Cable, 5. Installation Board, 6. (3 x M5*12, 2 x ST5.5*25, 2 x M5*40, 2 x M6*20, 2 x M6 Nut), 7. Cable Puller, 8. User Manual and Warranty Card.

Product	EcoFlow 800W Alternator Charger
Size	24.2 (L) x 19.4 (W) x 35 cm (H)
Weight	2.3 Kg
Charging Mode Input	11V – 31V, 76A Max
Charging Mode Output	40V – 60V, 800W Max
Battery Maintenance Mode Input	40V-60V, 3A Max
Battery Maintenance Mode Output	13.8V/27.6V, 100W Max
Reverse Charge Mode Input	40V-60V, 21A Max
Reverse Charge Mode Output	13.8V-27.6V, 800W Max
Rated Current of Fuse	125A
Protection Type	Reverse polarity protection Overcurrent protection Short circuit protection Overvoltage and undervoltage protection Thermal Resistance Gallium Nitride (GaN) Technology
Operating Temperature Storage Temperature	–4℉ to 140℉ (–20℃ to 60℃) –22℉ to 158℉ (–30℃ to 70℃)
Operating Humidity Storage Humidity	≤95% ≤95%
Maximum output power:	<20dBm
Warranty	2 Years
Connectivity	Wi-Fi & Bluetooth

Charge 1kWh in only 1.3 hours while you drive

Charge 8x faster while you drive with our EcoFlow 800W

Alternator Charger and recharge 1kWh in only 1.3 hours.

Time to fully recharge 1kWh (Eg. DELTA 2)

Car Cigarette Lighter Charger

12.6V 10A ~100W – 10 hours

EcoFlow 220W Bifacial Portable Solar Panel x 2

21.8V 13A 440W Max – 2.3 hours

EcoFlow Alternator Charger

40-60V 800W Max – 1.3 hours



Easy Install

Step 1: Fuse to Input Cable

Connect the fuse cable to the input cable on one end.

Step 2: Fuse to Battery

Connect the fuse cable to the vehicle battery on the other end.

Step 3: Black Cable to Chassis

Connect the black cable to the chassis terminal.

Step 4: Thread the Cable

Thread the other end of the input cable through the car body

towards the charger.

Step 5: Input Cable to Charger

Plug the other side of the input cable into the EcoFlow

Alternator Charger.

Step 6: Output Cable to Charger to Power Station

Plug in the output cable from the EcoFlow Alternator Charger

to the portable power station.



Compatible with the following models:

Ecoflow DELTA 2 and DELTA 2 Extra Battery, Ecoflow DELTA 2 Max and DELTA 2 Max Extra Battery, EcoFlow DELTA Pro (Smart Generator Adapter is required for the DELTA Pro/DELTA Pro 3) .

Ecoflow DELTA Max 1600 and 2000.



Please note: It is recommended to use a professional to complete this installation.
